  • PHỤ TÙNG CHO BƠM RA0010C ,RA0016C

  • Mô tả: Bao gồm ất cả phụ kiện và phụ tùng thay thế cho busch R 5 RA / RC 0010, 0016 C
  • Giá: Liên hệ
  • Lượt xem: 2089
Phụ tùng
Lưu ý: Khi đặt mua phụ tùng, phụ kiện...., vui lòng luôn trích dẫn loại (“Type”) và số sê-ri. (“No”) của máy bơm chân không. Điều này sẽ cho phép dịch vụ Busch kiểm tra xem máy bơm chân không có tương thích với bộ phận được sửa đổi hoặc cải tiến hay không.
Việc sử dụng các phụ tùng thay thế và vật tư tiêu hao chính hãng là điều kiện tiên quyết để thực hiện đúng chức năng của máy bơm chân không
Danh sách bộ phận này áp dụng cho máy bơm chân không Busch RA / RC 0010, 0016 C. Tùy thuộc vào các bộ phận sai lệch thứ tự cụ thể dữ liệu có thể áp dụng.

VỊ TRÍ MÃ SỐ MÔ TẢ
  0992 146 960, 992 146 960, 0992146960, 992146960 Service kit consisting of exhaust filter with o-ring, exhaust cover plate gasket, seal ring for oil fill plug, seal ring for oil drain plug
  0990 146 959, 990 146 959, 0990146959, 990146959 Set of seals/gaskets consisting of all necessary seals
  0993 146 962, 993 146 962, 0993146962, 993146962 consisting of seal set and all wearing parts (R.. 0010 C), RA0010C, RA 0010C ,RA0010C, RA_0010_C, 10m3
  0993 146 963, 993 146 963, 0993146963, 993146963 consisting of seal set and all wearing parts (R.. 0016 C), RA0016C, RA 0016C ,RA0016C, RA_0016_C, 16m3
Vị trí 18 0472 509 993, 472 509 993, 0472509993, 472509993 Sleeve
Vị trí 22 0724 105 206, 724 105 206, 0724105206, 724105206 Set of vane 60-18-4 mm, RA0010C, RA 0010C ,RA0010C, RA_0010_C, 10m3, RA0016C, RA 0016C ,RA0016C, RA_0016_C, 16m3
Vị trí 25 0947 000 719, 947 000 719, 0947000719, 947000719, 0947719, 947719 Filter spring
Vị trí 30 0947 501 331, 947 501 331, 0947501331, 947501331, 310062 Seal,Shaft,Viton, Sleeve bearing
Vị trí 35 0487 000 002, 487 000 002, 0487000002, 487000002, 0487002, 487002, 48700200 SEAL,SHAFT,VITON, Shaft seal
Vị trí 120 0532 140 154, 532 140 154,0532140154, 532140154 Exhaust filter RA0010C, RA 0010C ,RA0010C, RA_0010_C, 10m3, RA0016C, RA 0016C ,RA0016C, RA_0016_C, 16m3
Vị trí 120 0532 105 216, 532 105 216, 0532105216, 532105216 Exhaust filter RA0010C, RA 0010C ,RA0010C, RA_0010_C, 10m3, RA0016C, RA 0016C ,RA0016C, RA_0016_C, 16m3
Vị trí 120 0532 127 414, 532 127 414, 0532127414, 532127414 Exhaust filter RA0010C, RA 0010C ,RA0010C, RA_0010_C, 10m3, RA0016C, RA 0016C ,RA0016C, RA_0016_C, 16m3
  0534 000 056, 0534 000 056, 0534000056, 534000056, 0534056, 534056 Screen
  0532 000 005, 532 000 005, 0532000005, 532000005, 0532005, 532005, 53200500 Filter cartridge, paper, for inlet filter (optional/accessory)
  0532 121 861, 0532 121 861, 0532121861, 532121861 Filter cartridge, polyester, for inlet filter (optional/accessory)
Vị trí 440 0916 000 310, 916 000 310, 0916000310 , 916000310, 0916310, 916310 Gas ballast, complete
  0946 000 100, 946 000 100, 0946000100, 946000100, 0946100, 946100 Filter pressure gauge, for easy checking of the degree of clogging of the exhaust filter
  0945 000 130, 945 000 130, 0945000130, 945000130, 0945130, 945130 Inlet air filter, inlet-side, vertical, with paper cartridge, toseparate solids; for horizontal installationrotate the inlet flange by 180°
  0945 121 871, 945 121 871, 0945121871, 945121871 Inlet air filter, inlet-side, vertical, with polyester cartridge, food proof, to separate solids; for horizontal installation rotate the inlet flange by 180°
  0947 000 438, 947 000 438, 0947000438, 0947000438, 0947438, 947438 Vacuum regulating unit, to adjust the required working pressure, with hose nipple LW25
  0916 142 032, 916 142 032, 0916142032, 916142032 Inlet flange, connection thread G½"
  0947 000 062, 947 000 062, 0947000062, 947000062, 0947062, 947062 Exhaust cover plate, laminated paper
  0947 119 875, 947 119 875, 0947119875, 947119875 Exhaust cover plate with connection thread, connection thread G½"
  0947 000 007, 947 000 007, 0947000007, 947000007, 0947007, 947007 Exhaust cover plate with connection thread, connection thread G¾"
  0945 000 250, 0945 000 250, 0945000250, 945000250, 0945250, 945250 Exhaust filter, active carbon, for exhaust cover with connection thread G¾"
  0574 000 100, 574 000 100, 0574000100, 574000100, 0574100, 574100 Hose nipple, LW20, G½"
  0574 000 101, 574 000 101, 0574000101, 574000101, 0574101, 574101 Hose nipple, LW25, G¾"
  0450 000 502, 0450 000 502, 0450000502, 450000502, 0450502 Small flange, DN16, R½"
  0450 000 501, 450 000 501, 0450000501, 450000501, 0450501, 450501 Small flange, DN16, R¾"
  0450 000 503, 450 000 503, 0450000503, 450000503, 0450503, 450503 Small flange, DN25, R¾"
  0962 117 377, 962 117 377, 0962117377, 962117377 Liquid and dust separator STF 0100, to protect against solids and liquids on the suction side
  0965 117 783, 965 117 783, 0965117783, 965117783 Liquid separator,LSS 0100, to protect against condensate and liquids on the suction side
  0965 117 779, 965 117 779, 0965117779, 965117779 Liquid separator LSA 0100, to protect against condensate and liquids on the suction side, with automatic draining
  0964 117 612, 964 117 612, 0964117612, 964117612 Cyclone separator CYC 0016, for extracting liquids from gases and mixtures of gases
  0831 102 492, 831 102 492, 0831102492, 831102492 VM 068, Oil vacuum pump Mineral oil, 1 Liter packaging
  0831 131 846, 831 131 846, 0831131846, 831131846 VSL 068, Oil vacuum pump Mineral PAO, 1 Liter packaging
  0831 102 493, 831 102 493, 0831102493, 831102493 VM 068, Oil vacuum pump Mineral oil, 5 Liter packaging
  0831 131 847, 831 131 847, 0831131847, 831131847 VSL 068, Oil vacuum pump Mineral PAO, 5 Liter packaging
